Opis

Opis:

CBN Turning Insert CCMW040104S01035SET KBN525

Cecha szcz.:

RE (GTC – Corner radius): 0.4 mm
LE (GTC – Cutting edge effective length): 1.4 mm
S (GTC – Insert thickness): 1.8 mm
IFS (GTC – Insert mounting style code): 3
Corner radius (RE): 4
IC (GTC – Inscribed circle diameter): 4.3 mm
L (GTC – Cutting edge length): 4.366 mm
AN (GTC – Clearance angle major): 7 Degree
EPSR (GTC – Insert included angle): 80 Degree
Size: 401
TCE (GTC – Tipped cutting edge code): A
Description: CCMW
Grade: KBN525
TC (GTC – Tolerance class insert): M
HAND (GTC – Insert hand): N
