CBN Turning Insert – CPGB090304T00815ME KBN60M Popularny

Opis

Opis:

CBN Turning Insert CPGB090304T00815ME KBN60M

Cecha szcz.:

RE (GTC – Corner radius): 0.4 mm
LE (GTC – Cutting edge effective length): 1.9 mm
S (GTC – Insert thickness): 3.18 mm
Corner radius (RE): 4
IFS (GTC – Insert mounting style code): 4
IC (GTC – Inscribed circle diameter): 9.525 mm
L (GTC – Cutting edge length): 9.672 mm
AN (GTC – Clearance angle major): 11 Degree
EPSR (GTC – Insert included angle): 80 Degree
Size: 903
TCE (GTC – Tipped cutting edge code): B
Description: CPGB
TC (GTC – Tolerance class insert): G
Grade: KBN60M
COATING (GTC – Coating): MEGACOAT CBN
HAND (GTC – Insert hand): N
