Opis
Opis:
- Suitable for light brushing such as deburring, cleaning and polishing.
- Particularly suitable for brushing on small surfaces due to face-down use with the entire brush face applied to the workpiece.
- PFERD TOOLS offers a wide range of miniature brushes for precision work.
- These can be used on flexible shaft drives, micro motors or electric grinders.
- Brushes with aluminium oxide (AO) are less sharp-edged and aggressive compared with SiC.
- They are primarily suitable for polishing and smoothing finishes on soft metals.
- Plastic filament withstands temperatures up to 220 °C.
Cecha szcz.:
- Max. RPM: 18000 RPM
- RPM, optimum, from: 1200 RPM
- RPM, optimum, to: 5000 RPM
- Width, metric: 3 mm
- Mounting system: Shank
- Dia. cup: 10 mm
- Dia. filament material: 0.3 mm
- Dia. external, metric: 18 mm
- Dia. shank, metric: 2.34 mm
- Filament material: Aluminium oxide (AO)
- Grit size: 600
- Length, filament: 6 mm
- Length, total: 45 mm
Zaleta:
- Maximum precision and efficiency in work on delicate workpieces.
- Highly flexible, enabling optimal adjustment to the workpiece contour.
- Abrasive grains are embedded in flexible plastic filaments, which means that the filament works on the sides as well as at the tip.
Zastosowanie:
- Recommendations for use: Please observe the recommended rotational speeds. Use coolant for applications where large amounts of heat are produced.
- Applications: Cleaning; Deburring
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Aluminium
- Bronze
- Cast iron
- Cast steel
- Cobalt-based alloys
- Other non-ferrous metals
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Materials that can be worked: Aluminium; Bronze; Cast iron; Cast steel; Cobalt-based alloys; Other non-ferrous metals; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC)
- Max. RPM: 18000 RPM
- RPM, optimum, from: 1200 RPM
- RPM, optimum, to: 5000 RPM
- Width, metric: 3 mm
- Mounting system: Shank
- Dia. cup: 10 mm
- Dia. filament material: 0.3 mm
- Dia. external, metric: 18 mm
- Dia. shank, metric: 2.34 mm
- Filament material: Aluminium oxide (AO)
- Grit size: 600
- Length, filament: 6 mm
- Length, total: 45 mm
Zaleta:
- Maximum precision and efficiency in work on delicate workpieces.
- Highly flexible, enabling optimal adjustment to the workpiece contour.
- Abrasive grains are embedded in flexible plastic filaments, which means that the filament works on the sides as well as at the tip.
Zastosowanie:
- Recommendations for use: Please observe the recommended rotational speeds. Use coolant for applications where large amounts of heat are produced.
- Applications: Cleaning; Deburring
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Aluminium
- Bronze
- Cast iron
- Cast steel
- Cobalt-based alloys
- Other non-ferrous metals
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Materials that can be worked: Aluminium; Bronze; Cast iron; Cast steel; Cobalt-based alloys; Other non-ferrous metals; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC)
- Recommendations for use: Please observe the recommended rotational speeds. Use coolant for applications where large amounts of heat are produced.
- Applications: Cleaning; Deburring
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Aluminium
- Bronze
- Cast iron
- Cast steel
- Cobalt-based alloys
- Other non-ferrous metals
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Materials that can be worked: Aluminium; Bronze; Cast iron; Cast steel; Cobalt-based alloys; Other non-ferrous metals; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC)
- Aluminium
- Bronze
- Cast iron
- Cast steel
- Cobalt-based alloys
- Other non-ferrous metals
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Materials that can be worked: Aluminium; Bronze; Cast iron; Cast steel; Cobalt-based alloys; Other non-ferrous metals; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC)
