Opis
Wykonanie:
- H (hard)
Opis:
- Due to their hardness and flexibility, felt points are used when the exact form of geometric shapes has to be maintained.
- Mounted felt flap wheels are used for pre-polishing and high-gloss polishing on small to medium-sized components.
Cecha szcz.:
- Max. RPM: 20000 RPM
- RPM, optimum, from: 6300 RPM
- Shape: Cylinders with flaps
- Version: H (hard)
- Width, metric: 20 mm
- Dia. external, metric: 30 mm
- Dia. shank, metric: 6 mm
- Length, shank: 40
Zaleta:
- Can be profiled as desired, meaning they can also be used for tools with complex geometries.
- Precise retention of geometric shapes due to the hardness of these tools.
- Low thermal load on the workpiece.
Zastosowanie:
- Recommendations for use: For the best results, use at a recommended cutting speed of 5-10 m/s. This provides an ideal compromise between stock removal rate, surface quality, thermal load on the workpiece and tool wear. Use diamond polishing pastes and polishing paste bars. When applying a different polishing paste, use a new unused polishing tool. Use the hard version for pre-polishing of even surfaces. If very fine finishes need to be achieved, the soft and hard versions can be used successively.
- Applications: Polishing
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Aluminium
- Brass
- Bronze
- Cast steel
- Cobalt-based alloys
- Copper
- Fibre-reinforced thermosetting plastics (GRP, CRP)
- Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC)
- Nickel-based alloys (e.g. Inconell and Hastelloy)
- Stainless steel (INOX)
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Thermoplastics
- Titanium
- Titanium alloys
- Materials that can be worked: Aluminium; Brass; Bronze; Cast steel; Cobalt-based alloys; Copper; Fibre-reinforced thermosetting plastics (GRP, CRP); Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC); Nickel-based alloys (e.g. Inconell and Hastelloy); Stainless steel (INOX); Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC); Thermoplastics; Titanium; Titanium alloys
