Opis
Wykonanie:
- CAST EDGE
Opis:
- The cylindrical shape ZY is ideal for grinding bores, radii and contours.
- The CAST EDGE type is particularly well-suited to edge grinding and for grinding away sand contamination and metal contamination on grey and nodular cast iron in conjunction with high cutting speeds.
- Its main applications include removal of sharp burrs and grinding out sand contamination and metal contamination on cast material parts.
Cecha szcz.:
- PFERD TOOLS type: ZY 2025 6 CU 30 R5V CAST EDGE
- Max. RPM: 47700 RPM
- RPM, optimum: 38000 RPM
- Shape: W 205
- Version: CAST EDGE
- Width, metric: 25 mm
- Dia. external, metric: 20 mm
- Dia. shank, metric: 6 mm
- Grit size: 30
- Length, shank: 40
Zaleta:
- Highly dimensionally stable due to the high bond content.
- Economical to use due to the high edge stability even on low-speed tool drives.
Zastosowanie:
- Recommendations for use: CAST EDGE mounted points perform best at a cutting speed of 30 to 50 m/s.
- Applications: Deburring; Finishing; Grinding out; Grouting; Leveling; Surface work; Work on weld seams; Working on edges (chamfering, rounding)
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Annealed cast iron
- Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Materials that can be worked: Annealed cast iron; Grey/nodular cast iron (GG/GJL, GGG/GJS)
- The cylindrical shape ZY is ideal for grinding bores, radii and contours.
- The CAST EDGE type is particularly well-suited to edge grinding and for grinding away sand contamination and metal contamination on grey and nodular cast iron in conjunction with high cutting speeds.
- Its main applications include removal of sharp burrs and grinding out sand contamination and metal contamination on cast material parts.
Cecha szcz.:
- PFERD TOOLS type: ZY 2025 6 CU 30 R5V CAST EDGE
- Max. RPM: 47700 RPM
- RPM, optimum: 38000 RPM
- Shape: W 205
- Version: CAST EDGE
- Width, metric: 25 mm
- Dia. external, metric: 20 mm
- Dia. shank, metric: 6 mm
- Grit size: 30
- Length, shank: 40
Zaleta:
- Highly dimensionally stable due to the high bond content.
- Economical to use due to the high edge stability even on low-speed tool drives.
Zastosowanie:
- Recommendations for use: CAST EDGE mounted points perform best at a cutting speed of 30 to 50 m/s.
- Applications: Deburring; Finishing; Grinding out; Grouting; Leveling; Surface work; Work on weld seams; Working on edges (chamfering, rounding)
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Annealed cast iron
- Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Materials that can be worked: Annealed cast iron; Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Highly dimensionally stable due to the high bond content.
- Economical to use due to the high edge stability even on low-speed tool drives.
Zastosowanie:
- Recommendations for use: CAST EDGE mounted points perform best at a cutting speed of 30 to 50 m/s.
- Applications: Deburring; Finishing; Grinding out; Grouting; Leveling; Surface work; Work on weld seams; Working on edges (chamfering, rounding)
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Annealed cast iron
- Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Materials that can be worked: Annealed cast iron; Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Materials that can be worked:
- Annealed cast iron
- Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Materials that can be worked: Annealed cast iron; Grey/nodular cast iron (GG/GJL, GGG/GJS)
