Opis:
- Poliflex fine grinding tools are manufactured with high shape accuracy, outstandingly consistent quality and tight dimensional tolerances.
- They are ideally suited to fine grinding, structuring and preparations for polishing work, and are very frequently used for tool and mould-making applications.
- Mounted grinding wheel in cylindrical shape, for fine grinding of small surfaces.
- Poliflex fine grinding tools with the PUR bond are manufactured with green silicon carbide (SiC).
- The PUR bond is a very soft bond which is available in two hardness grades (PUR-W, PUR-MH).
- It is homogeneously interspersed with abrasive grain.
Cecha szcz.:
- Max. RPM: 35800 RPM
- RPM, optimum: 24000 RPM
- Shape: Cylinders
- Width, metric: 12 mm
- Abrasive: Silicon carbide SiC/C
- Dia. external, metric: 8 mm
- Dia. shank, metric: 3 mm
- Grit size: 80
- Length, shank: 30
- Bond: PUR-W
Zaleta:
- Highly flexible, enabling optimal adjustment to the contour.
- Cool and very gentle grinding thanks to open structure and elastic bond.
- Produces a fine, matt surface finish.
- Produces very good surface quality.
- High economic efficiency thanks to long tool life and high stock removal rate.
Zastosowanie:
- Recommendations for use: Depending on the intended use, profile using a dressing diamond or ceramic dressing stone at a low rotational speed. For the best results, use at a recommended cutting speed of 10-15 m/s.
- Applications: Step-by-step fine grinding; Structuring (matt finishing, brush matting and satin finishing)
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Aluminium
- Brass
- Cast steel
- Copper
- Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC)
- Stainless steel (INOX)
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Zinc
- Materials that can be worked: Aluminium; Brass; Cast steel; Copper; Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC); Stainless steel (INOX); Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC); Zinc
