PFERD TOOLS STEEL EDGE mounted point shape B 122 dia. 10×10 mm shank dia. 3 mm A46 for steel and cast steel Wysoka jakość

Opis

Opis:

• The STEEL EDGE type is particularly well-suited to edge grinding and deburring work on steel and cast steel components.
• Its applications also include grinding of chamfers in preparation for weld seams and grinding of contours.
• Series B mounted points are generally used on smaller or more delicate components, such as in tool and mould construction.
• Due to the special shapes, it is possible to grind in a variety of contours.
• The applications range from grinding out slits and grooves in hard-to-reach areas to machining bores and small holes as well as smoothing.

Cecha szcz.:

• Max. RPM: 90200 RPM
• RPM, optimum: 65000 RPM
• Shape: B 122
• Width, metric: 10 mm
• Dia. external, metric: 10 mm
• Dia. shank, metric: 3 mm
• Grit size: 46
• Length, shank: 30

Zaleta:

• Long tool life and low tool wear due to hard, dimensionally stable bond.
• Economical to use due to the high edge stability even on low-speed tool drives.
• Particularly well suited to work on edges.

Zastosowanie:

• Recommendations for use: STEEL EDGE mounted points perform best at a cutting speed of 25 to 40 m/s.
• Applications: Deburring; Finishing; Grinding out; Grouting; Leveling; Surface work; Work on weld seams; Working on edges (chamfering, rounding)
• Drive types: Flexible shaft drive; Straight grinder

Materiał:

• Materials that can be worked:
  • Cast steel
  • Steel
  • Materials that can be worked: Cast steel; Steel
