Opis
Opis:
- Suitable for light brushing such as deburring, cleaning and polishing.
- Particularly suitable for brushing on small surfaces due to face-down use with the entire brush face applied to the workpiece.
- PFERD TOOLS offers a wide range of miniature brushes for precision work.
- These can be used on flexible shaft drives, micro motors or electric grinders.
- Steel wire is the most common filament material.
- Brushes with steel wire as the filament material are especially well-suited to work on surfaces and deburring.
- PFERD TOOLS special wire has high tensile strength and bending fatigue strength.
- This ensures that the wire wears down in the optimal way, as well as a long tool life, even in extreme brushing applications.
- Steel wire withstands temperatures up to 300 °C.
Cecha szcz.:
- Max. RPM: 20000 RPM
- RPM, optimum, from: 5000 RPM
- RPM, optimum, to: 10000 RPM
- Width, metric: 3 mm
- Mounting system: Shank
- Dia. cup: 8 mm
- Dia. filament material: 0.1 mm
- Dia. external, metric: 15 mm
- Dia. shank, metric: 3 mm
- Filament material: Steel wire (ST)
- Length, filament: 5 mm
- Length, total: 45 mm
Zaleta:
- Maximum precision and efficiency in work on delicate workpieces.
- Highly flexible, enabling optimal adjustment to the workpiece contour.
- Long tool life through use of PFERD TOOLS special wire.
- Creates fine surfaces.
Zastosowanie:
- Recommendations for use: Please observe the recommended rotational speeds.
- Applications: Cleaning; Deburring; Derusting; Removing oxide layers; Paint stripping; Roughening
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Cast iron
- Cast steel
- Thermosetting plastics
- Elastomers
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Thermoplastics
- Wood
- Materials that can be worked: Cast iron; Cast steel; Thermosetting plastics; Elastomers; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC); Thermoplastics; Wood
- Max. RPM: 20000 RPM
- RPM, optimum, from: 5000 RPM
- RPM, optimum, to: 10000 RPM
- Width, metric: 3 mm
- Mounting system: Shank
- Dia. cup: 8 mm
- Dia. filament material: 0.1 mm
- Dia. external, metric: 15 mm
- Dia. shank, metric: 3 mm
- Filament material: Steel wire (ST)
- Length, filament: 5 mm
- Length, total: 45 mm
Zaleta:
- Maximum precision and efficiency in work on delicate workpieces.
- Highly flexible, enabling optimal adjustment to the workpiece contour.
- Long tool life through use of PFERD TOOLS special wire.
- Creates fine surfaces.
Zastosowanie:
- Recommendations for use: Please observe the recommended rotational speeds.
- Applications: Cleaning; Deburring; Derusting; Removing oxide layers; Paint stripping; Roughening
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Cast iron
- Cast steel
- Thermosetting plastics
- Elastomers
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Thermoplastics
- Wood
- Materials that can be worked: Cast iron; Cast steel; Thermosetting plastics; Elastomers; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC); Thermoplastics; Wood
- Recommendations for use: Please observe the recommended rotational speeds.
- Applications: Cleaning; Deburring; Derusting; Removing oxide layers; Paint stripping; Roughening
- Drive types: Flexible shaft drive; Straight grinder
Materiał:
- Materials that can be worked:
- Cast iron
- Cast steel
- Thermosetting plastics
- Elastomers
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Thermoplastics
- Wood
- Materials that can be worked: Cast iron; Cast steel; Thermosetting plastics; Elastomers; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC); Thermoplastics; Wood
- Cast iron
- Cast steel
- Thermosetting plastics
- Elastomers
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 1,200 N/mm² (< 38 HRC)
- Thermoplastics
- Wood
- Materials that can be worked: Cast iron; Cast steel; Thermosetting plastics; Elastomers; Steel, cast steel; Steel materials with a hardness > 54 HRC; Steels up to 1,200 N/mm² (< 38 HRC); Thermoplastics; Wood
