Turning Toolholder – S12F-SDLCL07 Nowy

Opis

Opis:

Turning Toolholder S12F-SDLCL07

Cecha szcz.:

CNSC (GTC – Coolant entry style code): 0
CXSC (GTC – Coolant exit style code): 0
GAMO (GTC – Rake angle orthogonal): 0 Degree
LAMS (GTC – Inclination angle): 0 Degree
RE (GTC – Corner radius, Pos. A): 0.4 mm
S (GTC – Insert thickness, Pos. A): 2.38 mm
HF (GTC – Functional height): 5.5 mm
WF (GTC – Functional width): 6 mm
IC (GTC – Inscribed circle diameter, Pos. A): 6.35 mm
AN (GTC – Clearance angle major, Pos. A): 7 Degree
B (GTC – Shank width): 11 mm
H (GTC – Shank height): 11 mm
DCON (GTC – Connection diameter machine side): 12 mm
LF (GTC – Functional length): 80 mm
KAPR (GTC – Tool cutting edge angle): 95 Degree
CZCMS (GTC – Connection size code machine side): 120
OAL (GTC – Overall length): 120 mm
MIID (GTC – Master insert identification): DCET070204
HAND (GTC – Cutting direction): L
