Wybór klientów PFERD TOOLS Tungsten carbide burr cylindrical with radius end WRC dia. 12x25mm shank dia. 6mm Z3P universal medium cross cut HICOAT

Opis

Opis:

• Cut 3 PLUS with HICOAT coating HC-FEP is characterized by its high hardness and wear resistance.
• It enables effective chip removal through improved anti-adhesion characteristics and is highly temperature-resistant.
• It allows for a longer tool life and use at higher cutting speeds in comparison with uncoated burrs.
• Cylindrical burr with radius end according to DIN 8032 with cut conforming to DIN 8033.
• Combination of cylindrical and ball-shaped geometries.
• PFERD TOOLS EFFICIENCY recommends burrs with the HICOAT coating for working for long periods with low levels of fatigue, whilst saving resources and achieving perfect results as quickly as possible.

Cecha szcz.:

• RPM from, grey cast iron, white cast iron: 16000 RPM
• RPM from, hardened, heat-treated steels over 1,200 N/mm²: 7000 RPM
• RPM from, rust and acid-resistant steels: 13000 RPM
• RPM from, steels up to 1,200 N/mm²: 16000 RPM
• RPM to, grey cast iron, white cast iron: 20000 RPM
• RPM to, hardened, heat-treated steels over 1,200 N/mm²: 12000 RPM
• RPM to, high-temperature-resistant materials: 16000 RPM
• RPM to, rust and acid-resistant steels: 12000 RPM
• RPM to, steels up to 1,200 N/mm²: 20000 RPM
• Cut: 3 PLUS HC-FEP
• Dia. external, metric: 12 mm
• Dia. shank, metric: 6 mm
• Length, cut: 25 mm
• Length, total: 65 mm

Zaleta:

• The highly accurate concentricity enables impactfree working without creating chatter marks. This considerably reduces wear on the tool and tool drive.

Zastosowanie:

• Recommendations for use: To ensure costeffective use of burrs, use a higher rotational speed and cutting speed. Use burrs with a shank diameter of 6 mm with drives with a power output from 300 watts.
• Applications: Cutting out holes; Deburring; Leveling; Milling; Milling out; Surface work; Work on weld seams
• Drive types: Flexible shaft drive; Tool machine; Automated centres; Straight grinder

Materiał:

• Materials that can be worked:
  • Annealed cast iron
  • Brass
  • Bronze
  • Case-hardened steels
  • Cast steel
  • Hard aluminium alloys
  • Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC)
  • Steel
  • Steel, cast steel
  • Steels up to 1,200 N/mm² (< 38 HRC)
  • Steels over 700 N/mm² (> 220 HB)
  • Steels up to 700 N/mm² (< 220 HB)
  • Tool steels
  • Materials that can be worked: Annealed cast iron; Brass; Bronze; Case-hardened steels; Cast steel; Hard aluminium alloys; Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC); Steel; Steel, cast steel; Steels up to 1,200 N/mm² (< 38 HRC); Steels over 700 N/mm² (> 220 HB); Steels up to 700 N/mm² (< 220 HB); Tool steels
