Wysoka jakość PFERD TOOLS diamond cut-off wheel D1A1R 400×4.5×40.0mm D852 (very coarse) for grey and nodular cast iron

Opis

Opis:

• Electroplated diamond cut-off wheels are used for both wet and dry grinding.
• Electroplated diamond cut-off wheels with grit size D 852 are exceptionally well-suited to machining grey cast iron and nodular cast iron (GG and GGG or GJL and GJS) as well as for use in robots.
• They are characterized by their particularly efficient cutting performance because of their large chip channels.
• PFERD TOOLS ERGONOMICS recommends diamond cut-off wheels for foundries as an innovative tool solution to sustainably reduce the dust produced during use.
• PFERD TOOLS EFFICIENCY recommends diamond cut-off wheels for foundries for working for long periods with low levels of fatigue, whilst saving resources and achieving perfect results as quickly as possible.

Cecha szcz.:

• Protective segment per side: no
• Shape: D
• Width, metric: 4.5 mm
• Blade thickness: 2.5 mm
• Dia. hole: 40 mm
• Dia. external, metric: 400 mm
• Grit size: D 852

Zaleta:

• Very long tool life.
• Ideal for work on deep areas because of the constant tool diameter.
• Easy and quick elimination of metal contamination.
• Minimized dust formation due to the monolayer coating and coarse chips.

Zastosowanie:

• Recommendations for use: To considerably reduce the level of noise during manual cutting, it is advisable to use clamping flange set SFS 76 (M14 thread: EAN 4007220595275, 5/8″ thread: EAN 4007220895856). The 400 mm diameter is suitable for stationary application.
• Applications: Cutting; Cutting out holes; Deburring; Grinding out; Grouting
• Drive types: Automated centres

Materiał:

• Materials that can be worked:
  • Grey/nodular cast iron (GG/GJL, GGG/GJS)
  • Materials that can be worked: Grey/nodular cast iron (GG/GJL, GGG/GJS)

  W dostawie:

  • Customer-specific tool solutions are available on request.
